Stax SRM-400S

€1,595.00

Driver unit for electrostatic earspeakers

Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.

Quantity:
Add To Cart

Driver unit for electrostatic earspeakers

Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.

Driver unit for electrostatic earspeakers

Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.

PRODUCT DETAILS

Type- All-stage FET configuration DC amplification driver unit

Frequency response- DC - 90kHz (with one SR-L500 MK2)

Gain- 60dB

Harmonic distortion- 0.01% or less (1kHz/100Vrms output)

Input impedance- 50k Ω (RCA), 50k Ω x 2 (XLR)

Maximum output voltage- 400Vrms (1kHz)

Bias voltage- DC 580V

Operating temperature / humidity- 0 to 35 degrees C / less than 90% (non condensing)

Input terminal- RCA x 1, XLR x 1(mutual exclusion input)

Output- RCA parallel output terminal

Power consumption- 30W

Dimension- 195 (W) x 102 (H) x 376 (D) mm (maximum protruding portion included)

Weight- 3.4kg
