Rotel RCD-1572MKII
The RCD-1572MKII follows Rotel’s proud tradition of delivering award-winning CD players since 1989 with accurate reproduction of the audio, an exceptional sense of space, accurate frequency response and an ultra-low noise floor.
The RCD-1572MKII follows Rotel’s proud tradition of delivering award-winning CD players since 1989 with accurate reproduction of the audio, an exceptional sense of space, accurate frequency response and an ultra-low noise floor.
The RCD-1572MKII follows Rotel’s proud tradition of delivering award-winning CD players since 1989 with accurate reproduction of the audio, an exceptional sense of space, accurate frequency response and an ultra-low noise floor.
DIMENSIONS (W × H × D)
431 × 104 × 320mm
17" × 4" × 12.6"
FRONT PANEL HEIGHT
2U / 88.1mm (3.5")
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
15W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
7.34kg (16.18lbs.)
TOTAL HARMONIC DISTORTION (THD)
0.0035% @ 1kHz
FREQUENCY RESPONSE
20Hz - 20kHz, 0 ±0.5dB
S/N RATIO (IHF "A" Weighted)
>118dB
DYNAMIC RANGE
>99dB
DIGITAL TO ANALOG CONVERTERS
Texas Instruments
CHANNEL BALANCE
± 0.5dB
CHANNEL SEPARATION
>118dB @ 10kHz
ANALOG OUTPUT LEVEL
Unbalanced (RCA): 2.2V
Balanced (XLR): 4.5V
DIGITAL OUTPUT
0.5V, Peak to Peak
ANALOG OUTPUT IMPEDANCE
Unbalanced (RCA): 100Ω
Balanced (XLR): 200Ω
LOAD IMPEDANCE
75Ω
