Rotel RA-1572MKII
The RA-1572MKII Integrated Amplifier brings your music to life with exceptional fidelity delivering 120 Watts of Class AB output into 8 ohms with deep, controlled bass energy.
The RA-1572MKII Integrated Amplifier brings your music to life with exceptional fidelity delivering 120 Watts of Class AB output into 8 ohms with deep, controlled bass energy.
The RA-1572MKII Integrated Amplifier brings your music to life with exceptional fidelity delivering 120 Watts of Class AB output into 8 ohms with deep, controlled bass energy.
PRODUCT DETAILS
Physical Specifications
DIMENSIONS (W × H × D)-
431 × 144 × 358mm
17" × 5.7" × 14.1"
FRONT PANEL HEIGHT- 3U / 132.6mm (5.25")
POWER REQUIREMENTS- 230V, 50Hz
POWER CONSUMPTION- 400W
STANDBY POWER CONSUMPTION- <0.5W
NET WEIGHT- 13kg (29lbs.)
Technical Specifications
BTU RATING (4Ω, 1/8th power)- 810 BTU/h
CONTINUOUS POWER OUTPUT- 120W/Ch (All channels driven, 8Ω)
THD- (20Hz–20kHz) <0.03%
FREQUENCY RESPONSE-
Line Level Inputs: 10Hz - 100kHz ±0.5dB
Digital Inputs: 10Hz - 90kHz ±2dB
Phono Input: 20Hz - 20kHz ±0.5dB
S/N RATIO (IHF "A" Weighted)-
Line Level Inputs: 100dB
Digital Inputs: 100dB
Phono Input: 80dB
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)- <0.03%
DAMPING FACTOR- 300
SPEAKER IMPEDANCE- 4Ω minimum
INPUT SENSITIVITY-
Line Level Inputs (RCA): 270mV
Line Level Inputs (XLR): 440mV
Phono Input (MM): 2.1mV
INPUT IMPEDANCE-
Line Level Inputs (RCA): 100kΩ
Line Level Inputs (XLR): 100kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
INPUT OVERLOAD-
Line Level Inputs (RCA): 4V
Line Level Inputs (XLR): 5.5V
Phono Input: 32mV
PREOUT LEVEL- 1.5V
OUTPUT IMPEDANCE- 470Ω
TONE CONTROLS- ±10dB at 100Hz / 10kHz
COAX/OPTICAL DIGITAL INPUT SIGNALS- LPCM (Up to 24-bit/192kHz)
PC-USB-
USB Audio Class 1 (up to 24/96)
USB Audio Class 2 (up to 32/384)*
*Driver installation required
DSD and DoP support
