Quad Artera Solus

PRODUCT DETAILS

Technical Specifications

General Description- CD Player, DAC, Pre-Amp, Integrated amplifier and Bluetooth Connectivity

Key Technology & Features- DSD (up to DSD256 Compatible) BIuetooth (aptX)

Audio File Formats- ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, AAC_HE, AAC+, DSD64, DSD128, DSD256

D/A Converter- ESS ES9018 32bit DAC

USB Input- USB B (PC / MAC)

Digital Audio Inputs- 2 x Optical TOSI ink, 2 x RCA(DIG1, DIG2)

Digital Audio Outputs- 1 x Optical TOSI ink, 1 x RCA (DIG)

Analogue Inputs- 2 x RCA (AUX1, AUX2)

Analogue Outputs- 2 x RCA, 2 x Balanced XLR, 6.3mm Headphone Jack

Speaker Outputs- Stereo Pair Binding Posts

Max. sample rates- 384kHz (USB), 192kHz (S/PDIF)

Sample Rate (Digital Inputs / Outputs)- 44.1 -192kHz

Standby Power Consumption- <0.5W

Pre-Amplifier Section

Output Level (1 kHz) Variable Output-
0 - 4 Vrms (Pre Outputs)
0 - 8 Vrms (Balanced Outputs)

Frequency Response- 20Hz-20kHz, 1 kHz (± 0.2dB)

Total Harmonic Distortion- <0.002% (20Hz-20kHz)

Signal to Noise Ratio (S/N)- >104dB A-weighted (ref: 1V , Volume=Max.)

Channel Separation- > 1 00dB (1 kHz)

Power Amplifier Section

Rated Power Output- 75Wpc (8ohms)

Frequency Response- ± 0.5dB (20Hz-20kHz, 1 kHz)

Total Harmonic Distortion- <0.009% (1 OW 20Hz-20kHz)

Signal to Noise Ratio (S/N)- >110dB A-weighted (ref: 75W)

Channel Separation- >82dB A-weighted (ref: 1W)

Dynamic Range A-wtd- 98dB

Physical Specifications

Dimensions- 320 x 320 x 105mm

Net Weight- 11.84kg
