Clearaudio Concept Signature MM
The Best concept Signature
The ideal of stress-free 'plug and play': unpack, connect – and just enjoy music.
The Best concept Signature
The ideal of stress-free 'plug and play': unpack, connect – and just enjoy music.
The Best concept Signature
The ideal of stress-free 'plug and play': unpack, connect – and just enjoy music.
PRODUCT DETAILS
CONSTRUCTION DETAILS-
Resonance-optimised turntable.
Upper layer incorporates high-tech satined plastic compound.
Chassis comprises medium-density wood fibre (silver / black) or pressure-formed solid wood (wood / dark wood).
Bottom plate medium-density wood fibre
Height-adjustable turntable feets.
SPEED OPTIONS- 33 ⅓, 45 rpm
DRIVE UNIT-
Decoupled and resonance damped 12V DC motor
Flat belt-drive
Plug-in power supply unit, designed for worldwide use with all networks and power frequencies.
„IMS light – Innovative Motor Suspension“ (Suspension design of the motor using O-rings)
„TSC“ Tacho speed control (speed monitoring)
Automatic compensation of friction and temperature changes on platter bearings and belts
BEARING- Polished and tempered steel spindle in a sintered bronze bushing, running on a teflon thrust-pad.
PLATTER- 30mm / 1.18 inch main platter, made out of synthetic material with high-density and excellent dimension / precision CNC machined aluminium sub-platter.
SPEED ACCURACY (MEASURED)- ± 0,05%
POWER CONSUMPTION- Max. consumption: 3.6 watts
Consumption in operation- 1.92 watts
Standby- 0.74 watts
Off mode- 0.0 watts (switched off at the rear)
TOTAL WEIGHT- Approx. 7.5kg (incl. tonearm and cartridge)
DIMENSIONS (W/D/H)- Approx. 420 × 350 × 125 mm (with tonearm)
DIMENSIONS (W/D/H)- Approx. 16.54 × 13.78 × 4.92 inches (with tonearm)
