Audio Analogue Maestro Anniversary

€7,450.00

DESCRIPTION

Maestro Anniversary was born in AIRTECH's laboratories following to the experience gained with the development of Puccini Anniversary. The basic scheme is very similar, but with one important difference: the amplification chain is fully balanced from the input to the power stage which becomes unbalanced to connect to the speakers. This took to a doubling of amplifier stages and attenuation. Also in the Maestro Anniversary all stages are without global feedback.

Colour:
Quantity:
Add To Cart

DESCRIPTION

Maestro Anniversary was born in AIRTECH's laboratories following to the experience gained with the development of Puccini Anniversary. The basic scheme is very similar, but with one important difference: the amplification chain is fully balanced from the input to the power stage which becomes unbalanced to connect to the speakers. This took to a doubling of amplifier stages and attenuation. Also in the Maestro Anniversary all stages are without global feedback.

DESCRIPTION

Maestro Anniversary was born in AIRTECH's laboratories following to the experience gained with the development of Puccini Anniversary. The basic scheme is very similar, but with one important difference: the amplification chain is fully balanced from the input to the power stage which becomes unbalanced to connect to the speakers. This took to a doubling of amplifier stages and attenuation. Also in the Maestro Anniversary all stages are without global feedback.

PRODUCT DETAILS

Technical Specifications

Channels- 2

RCA inputs- 3

XLR inputs- 2

Input impedance- 47KOhm

Maximum input signal- 6Vrms

Power on 8Ω load- 150W @ 1% THD + N

Power on 4Ω load- 300W @ 1% THD + N

Power on 2Ω load- 500W @ 1% THD + N

Sensitivity(8Ω output nominal power)- 720Rrms

Frequency Response(Att. 0dB, -3dB band)- 90KHz

Output resistance(2Ω nominal power and 1kHz)- 0.2Ohm

Input Noise(Band limits 0Hz-80kHz/A-weighted)- =20µV/=10µV

SNR- =100 dB

Physical Details

Standby power consumption(230VAC)- 0.7W

Dimensions(HxWxD)- 168x450x550 mm

Weight- 31 Kg
